Order Online @ www.ppmracingproducts.comSTEERING1-877-560-061992SWEET MFG POWER STEERING PUMPS & BRACKETSSWEET MFG KITSSERVOS / REPLACEMENT PARTSRACK GUARDSIntegrated Rack & Pinions are available in 11 different ratios with several different rack ends, center distances and servos. Every rack & Pinion is produced and assembled in the USA by Sweet Manufacturing.(A) RACKSPEED30 = 1-7/8%u201d40 = 2%u201d50 = 2-1/4%u201d60 = 2-1/2%u201d80 = 3%u201d90 = 3-1/4%u201d91 = 3-1/2%u201d92 = 3-3/4%u201d93 = 4%u201d94 = 4-1/4%u201d95 = 4-1/2%u201d(B) CENTERDISTANCE1 = 16-1/2%u201d2 = 17-1/4%u201d3 = 18-1/4%u201d5 = CUSTOM6 = 19-1/4%u201d7 = 19-3/4%u201d8 = 18/19-1/4%u201d(C) POWER ASSIST1 = Manual4 = Dual Power5 = XL Dual Power(D) RACK ENDS2 = On Center (5/8%u201d-18 Threaded Stud)3 = Rod End Eye (5/8%u201d-18 Threaded Hole)4 = On Cntr Rod End Eye5 = Standard Slotted Eye6 = Upside Down Slotted Eye7 = Dual Hole Rod End Eye (Rocket)8 = RH On Cntr Rod End - LH Rod End Eye11 = Slotted-RH Down - LH Up(E) SERVO.185 = XX Light.200 = X Light.210 = Light.220 = Light.235 = Med Light.250 = Medium.265 = Med Hvy.275 = HeavyWhen ordering your rack, just follow the numbering pattern shown, choosing the features you want005- 93(A) (B) (C) (D) (E)3 4 5 235Example: Part # 005-93345235 =RackSWE001-21110 ...............................................LH On Center Rod Eye DPCBSWE001-21111 ...............................................RH On Center Rod Eye DPCBSWE001-21103 ........................................ LH 5/8%u201d Rod End Rack Eye DPCBSWE001-21104 ........................................RH 5/8%u201d Rod End Rack Eye DPCBSWE001-21114 .................................. On-Center Rod End with Nut SpacersSWE001-21105 ....................................RH (Rocket) Double Rack Eye DPCBSWE001-21115 ................................... On Center Rack Eye Bolt & BushingsSWE001-21116 ...................................................LH Slotted Rack Eye DPCBSWE001-21117 ..................................................RH Slotted Rack Eye DPCBSWE001-21126 ............................LH Slotted Upside Down Rack Eye DPCBSWE001-21127 ........................... RH Slotted Upside Down Rack Eye DPCBSWE001-21128 ........................... RH Upside Down, Dbl Slot End w/DP BrktSWE001-21106-1 ..............................................RH Double Slotted Rack EyeSWE001-21118 ............................................Slotted Rack Eye Bolt Kit (each)SWE302-32200 ........................................ With .200 ValveSWE302-32210 ........................................ With .210 ValveSWE302-32220 ........................................ With .220 ValveSWE302-32235 ........................................ With .235 ValveSWE302-32250 ........................................ With .250 ValveSWE302-32275 ........................................ With .275 ValveSWE302-32101 .................................. Integrated Rack Replacement Line (Long)SWE302-32102 ..................................Integrated Rack Replacement Line (Short)SWE302-32063 ................................................Dual Power Cylinder (1 3/8%u201d bore) SWE001-21140 ..............................................................................Rack BushingsSWE001-21011 .................................. 16-7/16%u201d Rack Shaft for 18-1/4%u201d RackSWE001-21018 .................................. 17-7/16%u201d Rack Shaft for 19-1/4%u201d RackPower steering pump/mechanical fuel pump drive combination is designed for Bert/Brinn style bellhousing and flywheel. It allows any small block chevy mechanical fuel pump to be driven by a cam lobe located on the back of the power steering pump. The power steering pump comes complete with a 33 tooth HTD style pulley with guides. Fuel pump not included.SWE305-85839-K ............................................... Tandem Power Steering KitContains:SWE305-85839 .................(Sweet Aluminum Pump W/ HTD 33 tooth Pulley)SWE308-10100 ...................... (SBC Mechanical Fuel Pump Drive w/ Clamp)SWE325-30044 .....................................................(Bellhousing Pump Mount)SWE325-30059 ...................................................................(Phenolic Spacer)Tandem Mechanical Combination AssemblyPPM7020..............................Rack Guard .080 Aluminum PPM7021...................................Rack Guard - Rocket XR1PPM7022............................................. Rack Guard - LonghornPPM1470.............................................................Rack Plate (1/4%u201d Aluminum)SWE305-60331 ................................................... Aluminum Pump, 1300 psi with V-Belt Pulley - Engine MountSWE305-60334 ..........................Aluminum Pump, 1300 psi with 3/8%u201d Hex DriveSWE305-60335 ..................... Aluminum Pump, 1300 psi with Serpentine PulleySWE305-60339 ...........................Aluminum Pump 1300 psi with 33T HTD PulleySWE305-85839 .....Aluminum Pump, 1600 psi with Fuel Pump Drive 33T HTD PulleySWE325-30034 .................................................... Chevy Engine Block Mount KitSWE325-30030 ................................................................. Chevy Head Mount KitSWE325-30036 ............................Pump Bracket-to-Head Bolt Kit (for 325-30030)SWE325-30037 ............................................Pump/Bracket Bolt Kit (for 325-30030)SWE325-30039 ........................Pump Bracket-to-Block Bolt Kit (for 325-30034)SWE325-30049 ...........................................Trans Mount Pump Bracket w/ BoltsSWE305-60334 ........................................... Aluminum PTO Pump (No Brackets)SWE325-30057 ....................................................... PTO Rear Mount Adapter KitSWE325-30055 .......................................................Peterson/Toyota P/S AdapterSWE325-30060 .............................................Threaded Hex Drive for PTO PumpSWE301-30043 ............................................... HTD Pulley, 33-Tooth with GuidesSWE332-43230 .................................................1.375 ID Power Steering Seal Kit305-60331 305-60334305-60339INTEGRATED RACK & PINION STEERINGRACK EYES DPCB=Dual Power Cylinder Bracket
